Modular Designs Sliding glass luxury model house prefab homes container house

Parts

Part Name

Standard material

Optional

Top frame system

Upper corner piece

3.5mm upper corner piece, zinc plating amount 80g/㎡ 210*150*210mm

no

Main beam of roof (long)

3.0mm galvanized forming beam, zinc plating amount 80g/㎡, width: 170mm, length: 5633mm

2.0mm-3.0mm

Roof main beam (short)

3.0mm galvanized forming beam, galvanizing amount 80g/㎡, width: 170mm, length: 2688mm

2.0mm-3.0mm

Roof roof

75mm glass wool + tin foil paper, 14kg/m³

0.4mm-0.6mm

Roof insulation

C-shaped steel 90*1.3mm, square tube 20*20*1.0mm, galvanizing amount 80g/㎡

100mm

Roof secondary beam

0.4mm, 831 color steel integrated ceiling board, laminated

Negotiable

Ceiling board

Electrostatic spraying (white)

0.4mm-0.6mm

Surface treatment

3.5mm upper corner piece, galvanizing amount 80g/㎡ 210*150*160mm

Color can be customized
