LZQVMS-3020 Two-dimensional image measuring instrument/YVM
Model Number
LZQVMS-3020
Effective measuring stroke
300*200mm
Z-axis focus lifting range
≤200mm
Grating ruler resolution
0.0005mm
Z axis probe(Optional)
Renishaw probe (" tick "when the probe touches the product)
X and Y axis accuracy
U≤(2.5+L/200)μm (L unit: mm)
Table Size
560*360mm
Glass table size
328*228mm
Glass and carrying weight
High precision optical glass, bearing weight≤50kg
image system
STC High-definition color CCD from Japan
Image magnification
20-180X
Lens
Hong Kong (PMS) Pumice continuous double lens
Optical magnification level 0.7 x to 4.5
grating scale
Imported (grid) high precision grating ruler, resolution 0.0005mm
illuminating system
The surface light source and the bottom light source are LED, and the brightness is programmable
Drive Mode
X and Y axes Taiwan precision toothless transmission,linear guide
Z guide rail
Taiwan HIWIN high precision linear guide
operating mode
X, Y and Z axes are manually operated
Overall dimension
760*900*1650mm
Material of Machine base, Z-axis column
High precision granite
Weight
about 280KG
Software
Optical vision precision semi-automatic measurement software
data output
Metrical data Word(doc),Excel(xls),Object magnifies camera graphics(bmp、jpg), stereogram AutoCAD(dxf), data Word(doc), Excel(xls)
data input
stereogram AutoCAD(dxf))
power
AC 220±5V、50Hz
Recommended use environment
Temperature 20±2℃, humidity 35%-75%,
Vibration is less than 0.002g and less than 15HZ
