EBS4D Arrester Surge Protector Device SPD Manufacturers

Category: Industrial Controls
Brand: EBASEE
Tracking code: 6362757169
Description

    Model name EBS4U-40

    Standard IEC61643-11

    Poles 1P, 2P, 3P, 4P

    Max. continuous operation AC voltage Uc 275V AC

    Norminal discharge current (8/20μs) In 20kA

    Maximum discharge current (8/20μs) Imax 40kA

    Voltage protection level (L-N) Up 1.8kV

    Response time (L-N) tA 25ns

    Mounting 36mm Standard Guide

    Cross section of wire (Min.) 4mm2

    Cross section of wire (Max.) 35mm2

    Casing material Thermoplastic UL94-V0

    Dimension (L*W*H) 90*70*54mm
